Footwear and Bags: AR Try-On

The AR Try-On feature allows users to virtually try on shoes, bags, and backpacks in real-time using their mobile device's camera. It can be accessed via a direct link or by scanning a QR code.

Demo

Scan the AR code below or click this link on your mobile device: https://wearfits.com/demo-tryon

NEW

Check out our new solution for AR Shoes Try-On: Automatic 3D Model Generation from Photos

API

Implementing our AR shoe & bags try-on is as easy as:

Drag and drop your 3D shoe model (or use our automatic photo to 3D converter).
Copy the created link or QR code and share the try-on experience anywhere you like.
Fully automate the process via API for large volumes.

💡 The process of model positioning and occluder creation is automated!

Endpoints:

Endpoint	Description
`/tryon`	Provides the footwear AR Try-On experience. May be used as a direct link or via QR code. Currently supports product types such as shoes, bags, and backpacks. Additional parameters are described below.
`/tryon/dev`	Currently developed version with new functionalities. Do not use in production environment.

💡 Utility tool allowing for changing camera, quality, and mirroring options may be displayed by clicking 4 times in the top right corner of the Try-On Viewer.

Main query string parameters:

Parameter	Type	Description	Accepted Values	Default Value
`object` (required)	`string`	Specifies the object ID or URL to the 3D model (`.glb`) - it can be set also via `postMessage` ℹ️ Use `object=null` when loading object via postMessage `load_object`	Any valid URL or object ID	`null`
`color`	`string`	Colorset ID of the object	Any valid color name	`null`
`res`	`string`	Specifies the resolution of the camera input. Can be one of: `vga`, `hd`, `fhd`, `qhd`, `uhd`, `4k`, or a custom resolution like `1920x1200`	Any valid resolution string	`fhd`

Additional query string parameters:

Mirror Mode (mm>0)

Parameter	Type	Description	Accepted Values	Default Value
`mm`	`number`	Enables the Mirror Mode with chosen quality (use for digital screens only, not for mobile devices!)	`1` (basic mirror mode), `2` (hand detection, no masks), `3` (variant of 5), `4` (masking, no hands), `5` (hand & masking), `6` (masking beta, no hands yet)	`0` (not Mirror Mode)
`camera_id`	`string`	Specifies the camera device ID	`"string"`	`null`
`flip_x`	`number`	Specifies if the camera input on the `x` axis should be flipped	`0` or `1`	`0`
`flip_y`	`number`	Specifies if the camera input on the `y` axis should be flipped	`0` or `1`	`0`
`rotated`	`number`	Specifies if the camera input should be rotated	`0` or `1`	`0`

Bags & Backpacks

Parameter	Type	Description	Accepted Values	Default Value
`pose`	`number`	Enables try-on of bags, backpacks, and garments (do not use for shoes)	`0` or `1`	`0`
`calibration_data`	`string`	Calibration data (base64 encoded), used for bags (pose=1)	Valid base64 string	`null`
`user_height`	`number`	User height (cm) for accurate bag/backpack size calibration - it can be set also via `postMessage`	e.g. `165`	`null`
`no_height_selector_ui`	`number`	Disables Wearfits height selector UI (it still displays camera output but no heavy processing is done till user height is provided)	`0` or `1`	`0`

UI

Parameter	Type	Description	Accepted Values	Default Value
`banner_text`	`string`	Banner text	Any string	`null`
`banner_url`	`string`	Banner URL	Valid URL	`null`
`banner_icon`	`number`	Banner icon	`0` or `1`	`null`
`colorlist`	`number`	Shows color list	`0` or `1`	`0`
`loop`	`number`	Loops animation (used by animated objects)	`0` or `1`	`0`
`no_ui`	`number`	Hides all UI elements (set when using custom interface and `postMessage` communication)	`0` or `1`	`0`
`noloader`	`number`	Hides loader	`0` or `1`	`0`
`show_snapshot_button`	`number`	Shows snapshot button	`0` or `1`	`0`
`show_back_button`	`number`	Shows back button	`0` or `1`	`0`
`sound`	`string`	URL of sound to play	Valid URL	`null`

Development & Debug

Parameter	Type	Description	Accepted Values	Default Value
`quality`	`string`	Sets the rendering quality	`low`, `medium`, `high`, `auto`	`auto`
`pose_quality`	`number`	Sets pose detection quality (use with pose=1)	`1` (low), `2` (med), `3` (high - do not use on mobile devices)	`2`
`ml_model_url`	`string`	URL to the ML model in JSON format	Any valid URL or `small`, `medium`	`null`
`tf_backend`	`string`	Forces the AI backend to use	`webgpu`*, `wasm`, or `webgl`	`null` (auto selected)
`nocamera`	`number`	Disables camera and uses video as input	`0` or `1`	`0`
`debug_video_clip`	`string`	Debug video clip (used with nocamera=1)	Valid URL	`null`
`native_ml_version`	`string`	Native ML version to use	Valid version string	`null`
`object_scale`	`number`	Object scale	Any positive float	`1.0`
`object_collection_id`	`string`	Group ID used in demo. Allows user to change shoes within the group by swiping left or right. Group of models is defined by admin	`null`
`object_carousel_interval`	`number`	Used with object_collection_id, automatic shoe rotation time in seconds	Positive integer	`null`
`fps`	`number`	FPS limit	Positive integer	`null`
`zoom`	`number`	Camera zoom	Positive integer	`100`
`set_crop_region_from_pose`	`number`	Sets crop region from pose	`0` or `1`	`1`
`hide_one`	`number`	Hides shoes if only one foot is detected	`0` or `1`	`0`
`compose_method`	`string`	Composition method; changing may increase performance	`"canvas"`, `"scene"`, or `"shader"`	`"canvas"` (auto selected)
`masks`	`number`	Controls masking behavior (used for shoes): 0 (disable masks), 1 (automatic use masks on supported devices), 2 (force masks enabled on all devices)	`0`, `1`, or `2`	`1`
`device_info`	`number`	Displays device information, fps and resolution used	`0` or `1`	`0`
`settings`	`number`	Displays settings window (use for development only)	`0` or `1`	`0`
`masking_model_url`	`string`	Path to JSON to select different segmentation model for shoe masking	Any valid URL	`null`
`iframe_mode`	`number`	Use for URL in IFRAME implementation. It does not enable the camera (it is not computing) and does not load the default product. Use `enable_camera` via postMessage to start and stop the camera.	`0` or `1`	`0`

💡 webgpu mode offers the best performance but is not supported on all devices yet (iOS is supported from iOS 26).

IFRAME

Below, we explain how to communicate with the try-on app implemented via an IFRAME using postMessage. The IFRAME integration can be used in two main scenarios:

Embedding Try-On in Custom Web Apps:
Wrapping the WEARFITS try-on app inside an IFRAME lets you build your own custom UX, interface, or control elements around the core try-on experience. This approach is suitable when you want to apply your web app's styles, add unique flows, or interact with the IFRAME using the postMessage API for advanced controls (see below for message examples).
Digital Mirror Installations:
The IFRAME can also be used to embed the try-on app in digital mirror settings, such as a large screen with a connected camera in a brick-and-mortar retail space or digital signage environments. In this case, the app runs either in a browser or kiosk mode and provides a real-time virtual try-on experience to shoppers.
For digital mirror mode, ensure you add the mm parameter to the IFRAME URL (see documentation above) to enable features specifically designed for these environments, such as simplified user flow and on-screen mirror calibration.

This flexibility allows you to create both rich, branded try-on web integrations and robust in-store digital mirror experiences with the same WEARFITS try-on platform.

Digital Mirror Examples:

CodePen: https://codepen.io/wearfits/pen/poMjQOz
GitHub: examples/14-wearfits-digital-mirror-communication.html

Additional query string parameters:

All parameters from the API section above may be used, but there are also additional parameters available for digital mirror mode:

Parameter	Type	Description	Accepted Values	Default Value
`settings`	`number`	Allows for displaying mirror mode settings by 4-click in top-right corner	`0` or `1`	`1`
`calibration`	`number`	Displaying simplified settings for mirror calibration only	`0` or `1`	`0`

Communication between the web app and the digital mirror in an IFRAME is done using the postMessage API for sending messages to the IFRAME and receiving events.

Sending messages to the IFRAME:

Get a reference to the IFRAME's content window:

const tryon_iframe_element = document.getElementById('tryon_iframe').contentWindow;

Use postMessage to send a message:
```
tryon_iframe_element.postMessage(JSON.stringify(message), "*")
```
where message is an object with name and data properties (examples below).

Available commands:

Load an object (e.g., a shoe) model:
```
{
    "name": "load_object",
    "data": "<id>"
}
```
- Add to IFRAME URL param &object=null when loading object via postMessage load_object
- You can combine the object ID and color name using the format <id>~<color> to load an object in a specific color with a single message (e.g., "12345678~red").
Change color:

To change the color, use the load_object message as described above, and specify the desired color name together with the object ID in the format <id>~<color>.

Enable/disable camera (can be 0 or 1):

{
    "name": "enable_camera",
    "data": 0
}

Set tryon config:

{
    "name": "set_option",
    "key": "<config_key>",
    "value": "<config_value>"
}

For example, to set the user's height:

const message = {
    name: "set_option",
    key: "user_height",
    value: <value>,
}

postMessage(JSON.stringify(message), "*”);

Hand detection area configuration:

const message = {
    name: "set_option",
    key: "detector_positions",
    value: [
        {
            left: "1vw",
            top: "49vh",
            width: "7vh",
            height: "7vh",
        },
        {
            right: "2.5vw",
            top: "49vh",
            width: "7vh",
            height: "7vh",
        },
    ],
}

tryon_iframe_element.postMessage(JSON.stringify(message), "*")

Receiving messages from the IFRAME:

Add an event listener for the 'message' event on the window object.
Check if the message source is the IFRAME.
Parse the event data (it's a JSON string).
Handle the event based on its name.

Available events from the IFRAME:

Event Name	Description	Data Type
`loadingProgressHandler`	Triggered during app load	Loading progress percentage (`int`)
`loadingFinishedHandler`	Triggered when the app is loaded	null or an error code (`int`)
`objectLoadingProgressHandler`	Triggered during object loading	Object loading progress percentage (`int`)
`objectLoadingFinishedHandler`	Triggered when the object finishes loading	An object; error field is missing if the object is loaded successfully `{ id: string, error: int }`
`shoesVisibilityChangedHandler`	Triggered when feet visibility changes	A `boolean` indicating visibility
`objectVisibilityChangedHandler`	Triggered when object visibility changes (true when positioned and displayed/anchored)	A `boolean` indicating visibility
`heightSelectorVisibilityChangedHandler`	Triggered when height selector UI visibility changes	A `boolean` indicating visibility
`userHeightSelectedHandler`	Triggered when user selects height in height selector UI	Height in cm (`int`)
`detectorStateChanged`	Triggered when left or right hand enters or leaves the detection area	`data: { index: <0 - left detector, 1 right detector>, value: <true or false> }`
`calibrationParameter`	Triggered when `Save` button, after bag size calibration, is pushed	`{ name: "calibrationParameter", data: "&calibration_data=<...>" }`

Error codes:

Error Code	Error Message	Error Description
`1`	Unknown error	Any other errors not listed below
`10`	Camera error	Camera undefined error
`11`	Camera not found	Camera not found
`12`	Camera disabled in browser	navigator.mediaDevices.getUserMedia is undefined
`13`	Camera permission denied	Camera permission denied
`14`	Camera error	Camera device not readable
`15`	Camera disabled in browser	WKWebView without allowsInlineMediaPlayback
`20`	Device not supported	Failed to load ML model, unknown error
`21`	Device not supported	Failed to compile fragment shader
`30`	Load error	3D model load unknown error
`31`	Load error	3D model not found
`32`	Connection error	3D model download error
`33`	Unauthorized model URL	Unauthorized URL origin
`34`	Aborted loading	Connection aborted when trying to load a new object

SDK for iOS and Android

The preferred method is simple and quick browser-based integration, but we may also provide an SDK for native integration of the Footwear AR Try-On into iOS and Android apps. Ask us for more details.

Footwear: Scan and Fit

Our mobile app for iOS and Android allows users to scan their feet using just a smartphone camera. It provides precise foot measurements and personalized shoe size recommendations.

Footwear and Bags: 2D-to-3D Converter

Our web tool allows for the automatic conversion of 2D images to 3D models.
The converter demo is available at: https://tryon.wearfits.com/shoes
Anonymous service is limited and may be disabled at times. Files are deleted periodically.
Check this page for more information: Documentation
Contact us for more details.

3D and AR Viewer

This feature allows users to visualize any 3D objects (including shoes, bags, furniture, etc.) on the website in 3D and in an augmented reality environment. This is achieved by embedding the Viewer via the JavaScript API or by using an iframe. The AR visualization is available on mobile devices through a direct URL or by scanning a QR code.

Demo

A demo is available at: https://demo.wearfits.com

Admin Tool

The web editor allows for uploading and saving objects in multiple 3D formats.
The editor is available at: https://dev.wearfits.com/editor
After saving the object, you will get the object id with corresponding preview links for 3D, AR, and QR code.
Each object gets a unique URL allowing for editing and sharing: https://dev.wearfits.com/object/<id>
In our web editor, you can change textures, PBR parameters, lighting, scale, position, rotation, etc. One object may have multiple texture/color presets.
Objects representing shoes may be instantly enabled for AR Try-On.
Login to keep your models private. Anonymous uploads are public and are periodically deleted.
Contact us for an account and API integration.

Web App Endpoints

Endpoint	Description
`/editor`	Allows for uploading new objects and editing (e.g., textures, size, etc.). Login to keep your models private.
`/object`	Allows for managing and sharing the file (convert to try-on, edit, export to GLTF, delete), provides preview links (3D, AR, QR code).
`/viewer`	3D viewer which can be embedded into a website or used as a direct link to an object's 3D viewer. Additional parameters are described below.
`/viewar`	AR viewer with automatic detection of client device (iOS/Android), utilizes native system AR functionality.
`/tryon`	AR Try-On viewer used as a direct link or via QR code - currently supported types: shoes, bags, backpacks. Additional parameters are described below.

JavaScript API

Import the WEARFITS JavaScript library:

<script type="text/javascript" src="https://dev.wearfits.com/static/js/wearfits.bundle.min.js?"></script>

Create a DIV layer for the 3D visualization:
```
<div id="wearfits_viewer" style="width:100%; height:100%"></div>
```
You can customize the style but don't change the ID (wearfits_viewer).

Add JavaScript code:

<script>
    // Required parameters:
    wearfits.showRayTracingButton = false;
    wearfits.showARButton = true;

    // Optional parameters:
    wearfits.showMaterialPresets = true;
    wearfits.controlsType = "MOUSE_POSITION";

    // Required action:
    wearfits.load("<id>");
</script>

<id> is the object name set in the WEARFITS admin.

Multiple objects:

To load and visualize more objects in a 3D viewer, you can use the additional index parameter:
```
wearfits.load("<id>", {index:1});
```
The index number is the number of the object - default (first) is 0, and 1 is the second one, etc.

IFRAME

Use the /viewer endpoint in the IFRAME source:

<iframe style="width:100%;height:100%" src="https://dev.wearfits.com/viewer?object=<id>&<other_parameters>"></iframe>

Query String Parameters

Parameter	Type	Description	Accepted Values	Default Value
`object` (required)	`string`	Specifies the ID of the object to load	ID of the object (without `<` `>`)	`null`
`preset`	`string`	Specifies the object color variant name	Any valid color variant name	`null`
`nocolorlist`	`number`	Hides the color list if set to `1`	`0` or `1`	`0`
`norenderbutton`	`number`	Hides the HQ render button when set to `1`	`0` or `1`	`0`
`noarbutton`	`number`	Hides the AR button when set to `1`	`0` or `1`	`0`
`nofullscreen`	`number`	Disables the fullscreen mode when set to `1`	`0` or `1`	`0`
`autorotate`	`number`	Enables automatic rotation when set to `1`	`0` or `1`	`0`
`hidesettings`	`number`	Hides the settings panel when set to `1`	`0` or `1`	`0`

Example URL: https://dev.wearfits.com/viewer?object=backpack&preset=red&nocolorlist=1&autorotate=1

Shoe Upload and Processing REST API

Our system provides endpoints for uploading and processing 3D shoe models, with automatic positioning for AR try-on.

Upload Shoe API

Endpoint: POST /tryon/api/upload_shoe

This endpoint allows for uploading a 3D shoe model (.glb file) which will be automatically processed for AR try-on.

Request:

Content-Type: multipart/form-data
Authentication required: Yes (Bearer token in Authorization header)
Example: Authorization: Bearer your_api_token_here

Authentication

To use the API, you need to obtain an API token:

Get your user token
- Go to https://dash.wearfits.com
- Copy existing API token or click "Generate new token" button to create one
- Use this token in the Authorization header for API requests

Parameters:

Parameter	Type	Required	Description
`file`	File (.glb)	Yes	The 3D model file (max 30MB)
`right_shoe`	Boolean	No	Specifies if this is a right shoe model (default: false)

Response:

{
  "id": "model_id",
  "color_id": "default_color_id",
  "viewer_url": "https://example.com/viewer?object=model_id"
}

Error Codes:

Status	Error	Description
400	no_file	No file was provided in the request
400	unauthorized	User authentication is required
400	file_too_large	File exceeds the 30MB size limit
400	other errors	Other unspecified errors

Check Autofit Status API

Endpoint: GET /tryon/api/autofit_status

This endpoint allows you to check the automatic positioning status of an uploaded shoe model.

Parameters:

Parameter	Type	Required	Description
`id`	String	Yes	The model ID returned from the upload API
`color_id`	String	No	The color ID of the model variant

Response:

{
  "status": "in_progress",
  "progress": 45,
  "glb_url": null
}

Status Values:

in_queue - Model is waiting to be processed
in_progress - Model is currently being processed (with progress percentage)
exporting - Model has been processed and is being exported to GLB format
finished - Processing completed successfully
failed - Processing failed
interrupted - Processing was interrupted (user modified object while processing)
undefined - Status is unknown or not yet determined

Progress Values:

Range from 0 to 100, indicating the percentage of completion

Error Codes:

Status	Error	Description
400	no_id	No model ID was provided
400	object_not_found	The specified model ID was not found

💡 After uploading a shoe model, you should poll the autofit status endpoint until status is "finished" before using the model in AR try-on.

Contact

For any questions, inquiries, or to request an account, please email us at https://wearfits.com/contact?s=support

Go back to the main README.

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Footwear and Bags: AR Try-On

Demo

NEW

API

Implementing our AR shoe & bags try-on is as easy as:

Endpoints:

Main query string parameters:

Additional query string parameters:

Mirror Mode (mm>0)

Bags & Backpacks

UI

Development & Debug

IFRAME

Additional query string parameters:

Error codes:

SDK for iOS and Android

Footwear: Scan and Fit

Footwear and Bags: 2D-to-3D Converter

3D and AR Viewer

Demo

Admin Tool

Web App Endpoints

JavaScript API

IFRAME

Query String Parameters

Shoe Upload and Processing REST API

Upload Shoe API

Authentication

Check Autofit Status API

Contact

FilesExpand file tree

footwear_bags.md

Latest commit

History

footwear_bags.md

File metadata and controls

Footwear and Bags: AR Try-On

Demo

NEW

API

Implementing our AR shoe & bags try-on is as easy as:

Endpoints:

Main query string parameters:

Additional query string parameters:

Mirror Mode (mm>0)

Bags & Backpacks

UI

Development & Debug

IFRAME

Additional query string parameters:

Error codes:

SDK for iOS and Android

Footwear: Scan and Fit

Footwear and Bags: 2D-to-3D Converter

3D and AR Viewer

Demo

Admin Tool

Web App Endpoints

JavaScript API

IFRAME

Query String Parameters

Shoe Upload and Processing REST API

Upload Shoe API

Authentication

Check Autofit Status API

Contact
