TickSense

Real-time crypto market lakehouse built end-to-end.

Binance L2 WebSocket → Kafka → Flink → Iceberg on MinIO → dbt over Trino → FastAPI

~5M ticks/day · 50 pairs · <30s end-to-end freshness · Postgres CDC via Debezium

Demo

TickSense Demo

License

TickSense is licensed under the GNU Affero General Public License v3.0 only (AGPL-3.0-only). See LICENSE for the full license text.

Architecture

Binance WebSocket (L2 order book)
        │
        ▼
   Kafka (Redpanda)  ◄─── Debezium CDC ◄─── Postgres OLTP
        │
        ▼
   Flink (PyFlink)
   ├── normalize + deduplicate
   ├── order book state machine → spread, imbalance, microprice
   └── tumbling window → OHLCV 1m
        │
        ▼
   Iceberg on MinIO/GCS
   ├── raw.*        (append-only, full Kafka metadata)
   ├── normalized.* (typed, deduped)
   └── marts.*      (aggregated, API-facing)
        │
        ▼
   dbt over Trino → FastAPI

Getting started

Prerequisites

Tool Version Purpose
Docker Desktop ≥ 4.x All infrastructure services
uv ≥ 0.5 Python package manager for the main workspace
Python ≥3.12 3.13 recommended (Homebrew) Main workspace (ingest, api, replay)
Python 3.10 exactly 3.10 Flink IDE venv only (must be on PATH as python3.10)

Install uv:

curl -LsSf https://astral.sh/uv/install.sh | sh

Install Python versions via pyenv or python.org:

pyenv install 3.13 3.10   # if using pyenv

Step 1 — create the main Python environment

uv sync --all-packages   # creates .venv with Python 3.12 and installs all workspace members

This installs ingest, api, replay and all their dependencies. The --all-packages flag is required — plain uv sync only resolves the root package and leaves workspace members uninstalled. All uv run / make lint|test|typecheck commands use this venv automatically.

Step 2 — configure environment variables

cp .env.example .env

The defaults in .env.example work out-of-the-box for local development (MinIO, Redpanda, Postgres all use the Docker-compose credentials). No API keys are required — Binance public WebSocket data is used.

Step 3 — start the infrastructure stack

make up

Pulls and starts: Redpanda, MinIO, Iceberg REST, Trino, Postgres, Flink (jobmanager + taskmanager). Also submits both Flink jobs automatically via flink-init.

First boot pulls ~3 GB of images and takes a few minutes. Subsequent make up takes ~30s.

Once healthy, services are available at:

Service URL
Redpanda Console http://localhost:8080
MinIO Console http://localhost:9001 (minioadmin / minioadmin)
Flink UI http://localhost:8081
Trino UI http://localhost:8082
Iceberg REST http://localhost:8181/v1/config
TickSense API http://localhost:8000 (docs: /docs)
Prometheus http://localhost:9090
Grafana http://localhost:3000 (admin / admin)

Step 4 — create the Flink IDE venv (optional, for IDE navigation)

flink/ is not part of the uv workspace because apache-flink cannot be built from source with current pip/setuptools versions. Without this step, your IDE cannot resolve pyflink imports. The venv copies pyflink directly from the running container:

make flink-venv   # requires: make up has already been run

Then point your IDE at flink/.venv/bin/python:

  • VS Code: Cmd+Shift+P → Python: Select Interpreter → ./flink/.venv/bin/python
  • PyCharm: Settings → Project → Python Interpreter → Add → Existing → flink/.venv/bin/python

Re-run make flink-venv after make build if the Flink image is rebuilt.

Step 5 — start ingestion

The ingest service runs outside Docker (pure Python, no container needed):

uv run python -m ingest.main

This opens a WebSocket to Binance and streams L2 order book events into Redpanda. Stop with Ctrl+C — the producer flushes before exit.

Override symbols for a quick test:

INGEST_SYMBOLS=btcusdt uv run python -m ingest.main

Verify everything is flowing

# Flink: both jobs should show RUNNING
curl -s http://localhost:8081/jobs/overview | python3 -m json.tool

# Redpanda: messages arriving
docker compose exec redpanda rpk topic consume market.raw.orderbook \
  --brokers localhost:9092 --num 5

# Run all tests
make test

Verifying data is flowing

Redpanda — messages in topic

# Count messages in the raw orderbook topic
docker compose exec redpanda rpk topic consume market.raw.orderbook \
  --brokers localhost:9092 --num 5 --format json

# Lag per consumer group
docker compose exec redpanda rpk group list --brokers localhost:9092

# Topic metadata
docker compose exec redpanda rpk topic describe market.raw.orderbook --brokers localhost:9092

Redpanda Console (browser)

  1. Open http://localhost:8080
  2. Click Topics → market.raw.orderbook
  3. Click Messages — live stream of order book events

Trino — query Iceberg tables (Phase 2+)

# Interactive Trino CLI
docker compose exec trino trino --catalog iceberg

# From inside the CLI:
SHOW SCHEMAS FROM iceberg;
SHOW TABLES FROM iceberg.raw;
SELECT count(*) FROM iceberg.raw.orderbook_diffs;
SELECT symbol, count(*) FROM iceberg.raw.orderbook_diffs GROUP BY 1 ORDER BY 2 DESC;

Or open the Trino web UI at http://localhost:8082 and run queries there.

MinIO — check Iceberg data files

  1. Open http://localhost:9001 (login: minioadmin / minioadmin)
  2. Browse ticksense → warehouse → raw → orderbook_diffs
  3. Parquet files appear after Flink writes the first checkpoint

Stopping services

make down           # stop all containers AND delete volumes (clean slate)
docker compose stop # stop containers but KEEP volumes (data survives restart)
docker compose up -d --wait  # restart after `docker compose stop`

Use make down when you want a fresh environment. Use docker compose stop + up when you want to pause and resume without losing data.

Stack management

make up             # start full stack, block until healthy
make down           # stop + remove all volumes
make restart        # docker compose restart (rolling restart, keeps volumes)
make logs           # tail all service logs
docker compose logs -f redpanda   # tail a single service
docker compose ps                 # show running containers + ports

Checking individual service health

# Redpanda cluster
docker compose exec redpanda rpk cluster health --brokers localhost:9092

# Postgres
docker compose exec postgres pg_isready -U ticksense -d ticksense

# MinIO
curl -sf http://localhost:9000/minio/health/live && echo "OK"

# Iceberg REST
curl -sf http://localhost:8181/v1/config

# Trino
curl -sf http://localhost:8082/v1/info | python3 -m json.tool

Development commands

make lint           # ruff check + format check
make format         # ruff format + autofix
make typecheck      # mypy strict across all workspace members
make test           # pytest (unit + integration)
make coverage       # pytest --cov, fails below 80%
make dbt-compile    # compile dbt models
make dbt-run        # run dbt models
make dbt-test       # run dbt tests
make replay-sample  # replay 10k events dry-run
make watch-cdc      # tail postgres.public.symbol_config topic live
make build          # docker compose build --no-cache

Running only unit tests (no Docker needed)

uv run pytest ingest/tests/unit -v
uv run pytest --ignore=ingest/tests/integration -q

Flink IDE setup

flink/ is not part of the uv workspace because apache-flink cannot be built from source with current pip/setuptools versions. Without a local pyflink install, your IDE cannot resolve pyflink imports — go-to-definition and type hints will be broken.

The fix is a separate Python 3.10 venv (matching the container's runtime) that gets pyflink copied directly from the running flink-jobmanager container, bypassing the broken pip build entirely:

make up          # stack must be running first
make flink-venv  # creates flink/.venv with pyflink + py4j + cloudpickle

Then point your IDE at flink/.venv/bin/python:

  • VS Code: Cmd+Shift+P → Python: Select Interpreter → choose ./flink/.venv/bin/python
  • PyCharm: Settings → Project → Python Interpreter → Add → Existing → flink/.venv/bin/python

flink/.venv is covered by the existing .venv/ rule in .gitignore — it is never committed.

Re-run make flink-venv after make build if the Flink image is rebuilt.

Before commit

  • Run make lint typecheck test coverage to ensure tests have passed

Project layout

ingest/    Binance WebSocket ingestion → Kafka
  src/ingest/
    settings.py     pydantic-settings config
    models.py       BinanceDepthEvent, OrderBookEvent, DLQEvent
    orderbook.py    Order book state machine (snapshot + diff)
    producer.py     aiokafka producer, idempotent, DLQ routing
    client.py       Async WS client, reconnect, backoff
    main.py         Entry point: asyncio.gather over symbols

api/       FastAPI query layer over Trino + Iceberg
  src/api/
    read_model.py   in-process ReadModel (hot-path data, no Trino on reads)
    poller.py       background task: refreshes ReadModel every 30–60 s
    routers/        hot-path endpoints read model; cold-path (history) hits Trino
    models/         Pydantic response models per domain
replay/    Kafka offset replay producer
flink/     PyFlink streaming jobs (Phase 2)
airflow/   Orchestration DAGs (Phase 5)
dbt/       Analytics models: staging → intermediate → marts (Phase 4)
spark/     Backfill and compaction jobs (Phase 5)
infra/
  config/
    redpanda/     console.yaml
    trino/        config.properties, catalog/iceberg.properties
    debezium/     connector configs (Phase 3)
.skills/   Engineering playbooks for each layer
docs/      ROADMAP.md

Tech stack

Layer Technology
Ingestion Python 3.13, websockets, aiokafka, httpx
Broker Redpanda v24.3 (Kafka-compatible, no ZooKeeper)
Processing PyFlink 1.18
Storage Apache Iceberg 1.6 on MinIO (local) / GCS (cloud)
Catalog Iceberg REST (tabulario)
Query Trino 457
Analytics dbt
Orchestration Airflow
API FastAPI + Pydantic v2
CDC Postgres 16 + Debezium
Packaging uv workspace
Testing pytest, testcontainers, pytest-asyncio

Roadmap

See docs/ROADMAP.md for the full phase plan.

Phase Status Description
0 — Scaffolding ✅ CLAUDE.md, skills, uv workspace, CI, Makefile
1 — Local Stack + Ingest ✅ docker-compose, Binance WS → Kafka (57 tests, 96% cov)
2 — Flink Processing ✅ Normalize, dedup, OHLCV windows → Iceberg silver (e2e verified 2026-05-15)
3 — CDC + Replay ✅ Debezium CDC, Flink upsert job, replay CLI (e2e verified 2026-05-16)
4 — Analytics Layer ✅ dbt + Trino, FastAPI, Prometheus, Grafana (e2e verified 2026-05-16)
5 — Ops + Observability ✅ Airflow, Great Expectations, SLA alerts (load test: p(95)=10ms, 0% errors — 2026-05-18; Airflow/Spark pending E2E)
6 — Demo + Blog + Web — ticksense.ai, demo video, blog posts
