BALES - High-Throughput ML Inference Gateway

BALES Logo

Zero-downtime inference with dynamic batching and priority scheduling.

Python 3.14 CI Docker Build Coverage Pull Requests License: MIT

Quick Start • Architecture • Configuration • Running & Stress Testing • Benchmarking • Security • API Reference • Development

Overview

BALES is a production-ready inference gateway designed for high-throughput CPU-based ML serving. It combines Redis-backed priority queues, dynamic request batching, and atomic model hot-swapping to deliver:

  • >8,000 req/s throughput on CPU
  • P99 latency <12ms at batch_size=32
  • Zero-downtime model reloads without dropping in-flight requests

Built with FastAPI, PyTorch, and asyncio, BALES is engineered for safety-first concurrency: inference never blocks the event loop, and every request future is guaranteed to resolve or time out cleanly.

Table of Contents

Quick Start

Local Development

Prerequisites: Python 3.14+, Redis 7+, uv

# 1. Clone the repository
git clone https://github.com/ab1nv/bales.git
cd bales

# 2. Install dependencies (first time)
uv sync --extra dev

# 3. Start Redis (if not already running)
redis-server --save "" --appendonly no

# 4. Run the server
uv run python main.py

The gateway will be available at http://localhost:8000.

Docker

# Build and start everything (Redis + Bales)
docker compose up --build

# Optional: include Prometheus for metrics scraping
docker compose --profile monitoring up --build

Architecture

Data Flow

flowchart TD
    Client["Client"]
    Routes["FastAPI Routes"]
    Queue["Redis Priority Queue"]
    Consumer["Consumer Loop"]
    Batcher["Dynamic Batcher"]
    Torch["PyTorch run_in_executor"]
    Response["Response Future"]

    Client -->|POST /infer| Routes
    Routes -->|push request| Queue
    Queue -->|pop batch| Consumer
    Consumer -->|preprocess & submit| Batcher
    Batcher -->|stack tensors| Torch
    Torch -->|postprocess| Response
    Response -->|resolve future| Routes
    Routes -->|JSON response| Client
Loading

Key Invariants

  1. PyTorch inference NEVER runs on the event loop thread -- always dispatched via run_in_executor.
  2. A request NEVER touches a half-loaded model during hot-swap -- atomic reference replacement under an async lock.
  3. A request NEVER gets dropped during hot-swap -- in-flight requests hold a local reference to the old model until GC cleans up.
  4. request_id is the single source of truth linking API -> queue -> batcher -> response.
  5. pending_futures is the ONLY place futures are stored.

Configuration

All configuration is read from environment variables (with sensible defaults). Create a .env file from the example:

cp .env.example .env
Variable Default Description
REDIS_URL redis://localhost:6379/0 Redis connection string
MAX_BATCH_SIZE 32 Maximum requests per batch
BATCH_WINDOW_MS 5.0 Collection window in milliseconds
BATCHER_TIMEOUT_S 5.0 Client timeout before 504
DEFAULT_MODEL_ID stub_v1 Default registered model
THREAD_POOL_SIZE 4 Executor threads for torch inference
HOST 0.0.0.0 Server bind host
PORT 8000 Server port
LOG_LEVEL info Logging level
ENABLE_PROMETHEUS true Enable metrics export

Note: workers must remain 1 for in-process shared state (pending_futures). Scale horizontally with Docker replicas instead.

Running and Stress Testing

Start the Server

# Local (requires Redis running)
uv run python main.py

# Or with Docker (includes Redis)
docker compose up --build

The server will start on http://localhost:8000.

Smoke Test

Verify the server is healthy and can serve inference:

# Health check
curl http://localhost:8000/health

# Single inference request
curl -X POST http://localhost:8000/infer \
  -H "Content-Type: application/json" \
  -d '{
    "model_id": "stub_v1",
    "model_type": "classification",
    "payload": {"input": [0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 0.1, 0.2, 0.3]}
  }'

Note: The stub model expects exactly 128 floats in the input array. The example above is truncated for readability.

Stress Test with curl

Send 1000 sequential requests and measure total time:

# Generate a valid 128-element input
input_json=$(python3 -c "import json; print(json.dumps({'input': [0.1]*128}))")

# Sequential stress test
for i in {1..1000}; do
  curl -s -X POST http://localhost:8000/infer \
    -H "Content-Type: application/json" \
    -d "{
      \"model_id\": \"stub_v1\",
      \"model_type\": \"classification\",
      \"priority\": 2,
      \"payload\": $input_json
    }" > /dev/null
done

Concurrent Load with wrk or hey

For true concurrency testing, use a load generator:

Using hey (simple, single-threaded):

# Install: go install github.com/rakyll/hey@latest
# Or: apt-get install hey

# Run 50,000 requests with 500 concurrent connections
hey -n 50000 -c 500 -m POST \
  -H "Content-Type: application/json" \
  -d '{"model_id":"stub_v1","model_type":"classification","priority":2,"payload":{"input":[0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1]}}' \
  http://localhost:8000/infer

Using wrk (more accurate, multi-threaded):

# Install wrk first: https://github.com/wg/wrk/wiki/Installing-Wrk-on-Linux

# Create a Lua script for POST body
cat > infer.lua << 'EOF'
wrk.method = "POST"
wrk.headers["Content-Type"] = "application/json"
wrk.body = '{"model_id":"stub_v1","model_type":"classification","priority":2,"payload":{"input":[0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1]}}'
EOF

# Run with 12 threads, 400 connections, for 30 seconds
wrk -t12 -c400 -d30s -s infer.lua http://localhost:8000/infer

Monitor during stress test:

# Watch queue depth and pending requests
curl http://localhost:8000/health | python3 -m json.tool

# Watch Prometheus metrics
curl http://localhost:8000/metrics | grep bales_

Benchmarking

Isolated Batcher

Test pure batching throughput (no HTTP or Redis overhead). This tells you the theoretical maximum of the batching engine:

uv run python benchmarks/profile_batcher.py

Expected output:

=== Batcher Benchmark ===
Requests:          10,000
Elapsed:           1.23s
Throughput:        8,130 req/s
P50 latency:       2.45ms
P99 latency:       8.12ms
Avg batch size:    31.2
Model calls:       321  (vs 10000 individual = 31.2x reduction)
Target:            >8,000 req/s, P99 <12ms
Pass:              PASS

What to tune:

  • If throughput is low (< 8,000): increase BATCH_WINDOW_MS slightly (try 5ms -> 8ms) to allow more requests to accumulate per batch
  • If P99 is high (> 12ms): reduce BATCH_WINDOW_MS (try 5ms -> 3ms) or increase THREAD_POOL_SIZE
  • If avg batch size is low (< 20): increase concurrent load or reduce window

Full-Stack Load Test with Locust

Benchmark the complete HTTP -> Redis -> Batcher pipeline:

# Install locust (already in dev dependencies)
uv sync --extra dev

# Run headless load test
uv run locust -f benchmarks/locustfile.py \
  --headless -u 500 -r 100 \
  --run-time 60s --host http://localhost:8000

Parameters explained:

  • -u 500: spawn 500 concurrent users
  • -r 100: hatch 100 users per second
  • --run-time 60s: run for 60 seconds
  • --host http://localhost:8000: target the local server

After the run, Locust prints:

  • Total requests per second (RPS)
  • Average, median, and percentile latencies
  • Failure count and error rate

Interpreting Results

Metric Target What to do if failing
Throughput > 8,000 req/s Increase -u (users) in Locust. Check CPU usage with htop.
P99 latency < 12ms Reduce BATCH_WINDOW_MS or increase THREAD_POOL_SIZE. Check /health for queue backlog.
Error rate 0% Check logs for timeout or Redis connection errors. Verify pending_futures is 0 in /health.
Avg batch size > 20 Should be close to MAX_BATCH_SIZE (32). If low, increase load or window.

Comparison checklist:

  1. Run profile_batcher.py first to establish the ceiling (no HTTP/Redis overhead)
  2. Run locustfile.py to measure real-world throughput
  3. Compare: locust RPS should be ~60-80% of profile_batcher RPS due to HTTP + Redis overhead
  4. If gap is larger: HTTP layer or Redis is the bottleneck, not the batcher
  5. If gap is small: batcher is the bottleneck, tune THREAD_POOL_SIZE or BATCH_WINDOW_MS

Security

BALES follows security best practices:

  • Input validation: All requests are validated via Pydantic v2 before entering the pipeline.
  • No shell execution: weights_path in hot-swap is validated with Path.exists() and never passed to shell commands.
  • Resource limits: Docker Compose enforces CPU (4.0) and memory (2G) caps.
  • No Redis persistence: Queue data is ephemeral by design (--save "" --appendonly no) to avoid I/O overhead and accidental data retention.
  • Single worker: Prevents shared-state corruption; horizontal scaling is done via container replicas behind a load balancer.
  • Healthchecks: Docker HEALTHCHECK polls /health every 10s to detect degraded state.
  • Non-root container: The Docker image runs as an unprivileged bales user.

API Reference

POST /infer

Submit an inference request.

Request body:

{
  "model_id": "stub_v1",
  "model_type": "classification",
  "priority": 2,
  "payload": {
    "input": [0.1, 0.2, ...]
  }
}

Response:

{
  "request_id": "uuid",
  "model_id": "stub_v1",
  "result": { "label": 3, "confidence": 0.95 },
  "latency_ms": 4.123,
  "batch_size": 16,
  "queued_ms": 1.234
}

GET /health

Returns system health, registered models, queue depths, and pending request count.

curl http://localhost:8000/health

POST /models/{model_id}/reload

Hot-swap a model's weights without dropping traffic.

Request body:

{
  "weights_path": "./weights/new_model.pt"
}

Example:

curl -X POST http://localhost:8000/models/stub_v1/reload \
  -H "Content-Type: application/json" \
  -d '{"weights_path": "./weights/stub_v2.pt"}'

GET /metrics

Prometheus scrape endpoint exposing:

  • bales_requests_total - Total inference requests by model_id and status
  • bales_request_latency_ms - End-to-end latency distribution
  • bales_batch_size - Number of requests in each dispatched batch
  • bales_queue_depth - Number of requests waiting in priority queue
curl http://localhost:8000/metrics

Development

# Run the test suite (requires Redis on localhost:6379)
uv run pytest tests/ -v

# Run a specific test file
uv run pytest tests/test_integration.py -v

# Run with coverage
uv run pytest tests/ -v --cov=. --cov-report=html

# Profile the batcher
uv run python benchmarks/profile_batcher.py

# Run the load test
uv run locust -f benchmarks/locustfile.py --headless -u 500 -r 100 --run-time 60s --host http://localhost:8000

# Lint check
uv run ruff check .

# Format check
uv run ruff format --check .

# Type check
uv run ty check

Built with FastAPI + PyTorch + Redis + uv
