Adds a GraphQL client stack that mirrors the existing OpenAPI/gRPC
"spec -> generated typed client" architecture, plus two enabling
enhancements.
GraphQL:
- Runtime com.codename1.io.graphql: GraphQL invoker (HTTP POST queries/
mutations + decodeJson + encodeVariables), GraphQLResponse (data and
errors co-exist), GraphQLError, GraphQLClients registry, and
GraphQLSubscription over com.codename1.io.WebSocket (graphql-transport-ws).
- Annotations com.codename1.annotations.graphql: @GraphQLClient,
@Query/@Mutation/@subscription, @var (reuses @Header and @mapped).
- GraphQLClientAnnotationProcessor emits <Name>Impl + cn1app.GraphQLClientBootstrap.
- cn1:generate-graphql mojo with hand-written SDL + operation-document
parsers; precise operations mode and schema-only bounded-depth mode.
- Bootstrap wired into JavaSEPort + Executor like the REST/gRPC ones.
@mapped enum binding:
- AnnotatedClass.isEnum() + PropertyTypeKind.enumType(); MappingAnnotationProcessor
upgrades REFERENCE->ENUM and detects List<Enum>, emitting name()/valueOf
(unknown -> null) across JSON and XML. GraphQL response/input fields now
use real enum types.
WebSocket subprotocols:
- WebSocket.subprotocols(String...) + getSelectedSubprotocol(), threaded
through WebSocketImpl. Sec-WebSocket-Protocol implemented in JavaSE,
Android, iOS (webSocketTaskWithURL:protocols: + didOpenWithProtocol:),
and JavaScript. GraphQL subscriptions offer graphql-transport-ws.
Tests: GenerateGraphQLMojoTest, GraphQLClientAnnotationProcessorTest,
GraphQLResponseTest, plus enum round-trip and subprotocol negotiation
tests for the mapper and WebSocket (core mock + JavaSE RFC 6455 echo).
Co-Authored-By: Claude Opus 4.8 (1M context) <noreply@anthropic.com>
Summary
Adds a GraphQL client stack that slots into the same "spec → generated typed client" architecture as the existing OpenAPI (
@RestClient) and gRPC (@GrpcClient) support, plus two enabling enhancements that the GraphQL work needed and that stand on their own.GraphQL (
cn1:generate-graphql+@GraphQLClient)com.codename1.io.graphql:GraphQLinvoker (HTTPPOSTqueries/mutations, publicdecodeJson/encodeVariables),GraphQLResponse<T>(data and errors co-exist for partial results),GraphQLError,GraphQLClientsregistry, andGraphQLSubscriptionover the new corecom.codename1.io.WebSocketusing thegraphql-transport-wsprotocol.com.codename1.annotations.graphql:@GraphQLClient,@Query/@Mutation/@Subscription,@Var(reuses@Headerand@Mapped).GraphQLClientAnnotationProcessoremits<Name>Impl+cn1app.GraphQLClientBootstrap, registered in the annotation-processor SPI and wired intoJavaSEPort/Executorexactly like the REST/gRPC bootstraps.cn1:generate-graphqlwith hand-written SDL + operation-document parsers. Two modes: precise operations mode (per-selection@Mappedtypes, fragments inlined, operation document embedded verbatim) and a schema-only quick-start mode (bounded-depth auto-selection,cn1.graphql.maxDepth).@Mappedenum bindingPreviously an enum-typed field was classified as a nested reference, found no mapper, and silently didn't serialise. Now
AnnotatedClass.isEnum()+PropertyTypeKind.enumType()letMappingAnnotationProcessorupgradeREFERENCE → ENUM(and detectList<Enum>), emittingname()on write andvalueOfon read (unknown values decode tonull) across both JSON and XML. GraphQL response/input fields now use real enum types instead ofString.WebSocket subprotocols (
Sec-WebSocket-Protocol)The core
WebSocketfacade gainssubprotocols(String...)+getSelectedSubprotocol(), threaded throughWebSocketImpl. Implemented across every port: JavaSE + Android hand-rolled handshakes, iOS (webSocketTaskWithURL:protocols:+didOpenWithProtocol:, with the matchingIOSNativebridge rename), and JavaScript (new WebSocket(url, protocols)+w.protocol). GraphQL subscriptions offergraphql-transport-wsduring the handshake.Tests
GenerateGraphQLMojoTest(operations + schema-only modes, fragments, enum/input emission, records vs classes),GraphQLClientAnnotationProcessorTest(impl/bootstrap,GraphQL.execute/subscribe, error cases), and a new enum round-trip case inMappingAnnotationProcessorTest.GraphQLResponseTest(envelope decode, partial errors, variable encoding) and a subprotocol case inWebSocketTest.JavaSEWebSocketImplTest.All of the above pass locally (34 GraphQL/mapping/WebSocket tests) against the current master base.
Test plan
cd maven && mvn install -Plocal-dev-javase -DskipTests— core + plugin compile.mvn -pl codenameone-maven-plugin test -Dtest=GenerateGraphQLMojoTest,GraphQLClientAnnotationProcessorTest,MappingAnnotationProcessorTestmvn -DunitTests -pl core-unittests test -Dtest=GraphQLResponseTest,WebSocketTestmvn -pl javase test -Dtest=JavaSEWebSocketImplTest./scripts/build-android-port.sh -DskipTests— Android handshake change compiles../scripts/build-ios-port.sh -DskipTests— iOS nativeWebSocketImpl.m+IOSNative.mbridge compile under ParparVM.🤖 Generated with Claude Code
