audiorecorder (ra)

A macOS command-line audio recorder that writes 24-bit CAF files, targeting sessions up to 15+ hours. It compiles to a single binary with no dependencies beyond macOS system frameworks. The design centers on these features:

• No dropped audio during disk hesitation: audio capture and file writes run on separate threads with a 60-second internal buffer between them (lock-free ring buffer decoupling the CoreAudio real-time callback from disk I/O)
• Low power usage: the writer thread wakes on demand via semaphore rather than polling
• No lost sessions to system sleep: prevents idle sleep while recording
• Disk space validation: the recorder checks available space before recording and warns or stops if there isn't enough room for the requested duration
• Visual level meter: the display shows per-channel level bars with peak hold and clip detection
• Input monitoring: optionally play the input signal through the default output device during recording (--monitor)
• Safe output naming: if the output file already exists, the recorder appends _1, _2, etc.
• Test mode: --test captures audio and displays the level meter without writing a file
• Post-session summary: reports peak audio level with clipping detection; --verbose adds ring buffer high-water mark

Output Format

• Format: CAF (Core Audio Format)
• Sample rate: Matches the input device (typically 44100 or 48000 Hz)
• Bit depth: 24-bit signed integer, packed
• Channels: Stereo or mono depending on device

Usage

ra [options]

  -o, --output <path>       Output file path (default: ./Recording_YYYYMMDDTHHMMSS.caf)
  -d, --device <#|name|uid> Input device by number, name, or UID (default: system default)
  -l, --list-devices        List available input devices and exit
  -M, --monitor             Play input through default output device
  -t, --test                Test mode: capture audio without writing a file
  -D, --max-duration <min>  Stop after N minutes (default: unlimited)
  -q, --quiet               Suppress level meter display
  -v, --verbose             Print diagnostic output (buffer health, overruns)
      --extend <input.caf>  Extend mode: pad an existing ra recording (requires --pad-to and -o)
      --pad-to <min>        Target declared duration in minutes (extend mode)
  -h, --help                Show this help
  -V, --version             Show version and exit

Examples

List input devices:

ra -l

Record from device 2, stop after 60 minutes:

ra -d 2 -D 60 -o recording.caf

Record from the default device with no time limit:

ra -o recording.caf

Extend mode

Motivation: when stitching several equally-sized recording chunks into a single long session in Logic Pro, extend mode fabricates a file at the target duration in a few seconds so the timeline is already the right length to drop the other chunks onto.

ra --extend <input.caf> --pad-to <minutes> -o <output.caf> produces a new CAF whose declared duration is at least <minutes> minutes long, using a sparse hole for the padded region so the file consumes no additional disk space on APFS. The intended workflow is to open the padded output in Logic Pro, edit additional audio into the extended range, and export. The padded file is a disposable intermediate; the padded region decodes as silence.

ra --extend recording.caf --pad-to 90 -o recording_padded.caf

Only ra-produced CAF files are accepted as input. Extend mode requires --extend, --pad-to, and -o together; no other options may be combined with it.

-o follows the same path rules as recording mode: ~/ is expanded, .caf is appended if missing, and if the resulting path already exists the output is written to <stem>_1.caf, <stem>_2.caf, and so on. The success message prints the final path. Delete the prior padded file before re-running if you want the same name reused.

Architecture

The ring buffer decouples real-time audio capture from disk I/O. CoreAudio delivers samples to the callback, which pushes them onto the ring and signals the writer thread. The writer drains the ring and writes to disk through ExtAudioFileWrite.

Source modules

src/
  main.cpp            Entry point -- parses args, dispatches to session
  args.h/cpp          CLI argument parsing and usage display
  session.h/cpp         Session lifecycle: setup, recording loop, summary
  capture.h/cpp         CoreAudio input unit setup and callback
  monitor.h/cpp         CoreAudio output unit for input monitoring
  output_file.h/cpp     CAF file creation
  writer.h/cpp          Writer thread: ring drain, file write
  display.h/cpp         Level meter rendering and display loop
  extend_caf.h/cpp      Extend mode: pad CAF recording via sparse hole
  signal_handler.h/cpp  Signal registration for graceful shutdown
  sleep_guard.h         RAII guard to prevent idle sleep during recording
  recording_context.h   Shared recording state and RAII resource guards
  device.h/cpp          Audio device enumeration and selection
  file_util.h/cpp       Path resolution and disk space utilities
  ring_buffer.h         Lock-free SPSC ring buffer
  util.h                Formatted stderr output

Building

See BUILDING.md.

When to Use Something Else

• Cross-platform support: ffmpeg or sox run on Linux and Windows.
• Real-time compression: If recording directly to MP3, AAC, or FLAC is needed to save disk space.
• Live processing: If real-time effects (EQ, compression) or complex signal routing are required.
• Advanced metadata: If BWF/iXML embedding for archival purposes is needed.

License

MIT. See LICENSE.
