Kinetic Mirror Matrix (ESP32)

Firmware + host tools to drive up to 8 stepper-driven mirrors from a single ESP32 using FastAccelStepper for motion and two 74HC595 shift registers for per-motor DIR and SLEEP. A simple human-readable serial protocol provides immediate control from any laptop; diagnostics and thermal run-time limits keep demos stable and safe.

Quick Links: Build & Deployment · Wiring Guide · Control UI · Tech Stack

What It Does

• Multi-controller support via MQTT: Control multiple ESP32 nodes from a single CLI/TUI session
• Dual-network Wi-Fi: Primary + secondary credentials with automatic failover; safely update credentials fleet-wide via MQTT
• OTA firmware updates: Update firmware and filesystem over the network via PlatformIO
• Real-time telemetry: MQTT-based status publishing (1-5 Hz) with per-motor state
• Serial and MQTT command interface: Human-readable protocol (MOVE, HOME, STATUS, etc.)
• Drives 8 DRV8825 steppers concurrently (configurable microstepping: full to 1/32, default 1/32)
• Auto-sleeps motors to avoid overheating; runtime/cooldown thermal budgets
• Bump-stop homing with configurable overshoot and backoff
• Python CLI with interactive TUI for quick testing and live control

Architecture

flowchart LR
  subgraph "Host PC"
    CLI["mirror_cli"]
  end

  subgraph "ESP32 Firmware"
    Console["SerialConsole"]
    MCP["MotorCommandProcessor"]
    MC["MotorController"]
    HWC["HardwareMotorController"]
    FAS["FasAdapterEsp32"]
    SR["Shift595Vspi"]
  end

  subgraph "Hardware"
    DRV["DRV8825 Drivers"]
    SRIC["74HC595 Shift Registers"]
    Motors["Stepper Motors 0..7"]
  end

  CLI -->|USB Serial| Console
  Console --> MCP --> MC --> HWC
  HWC --> FAS -->|STEP GPIO| DRV
  HWC --> SR -->|VSPI| SRIC -->|DIR/SLEEP| DRV
  DRV --> Motors

Loading

Quickstart

Prerequisites: PlatformIO Core (CLI), Python 3.13+ with Poetry

# Build & upload firmware
pio run -e esp32DedicatedStep -t upload
pio device monitor -b 115200               # Verify: CTRL:READY Serial v1

# Build & upload filesystem (Wi-Fi portal)
pio run -e esp32DedicatedStep -t buildfs && pio run -e esp32DedicatedStep -t uploadfs

# Multi-device OTA deployment
cp tools/deploy/ota_devices.toml.example tools/deploy/ota_devices.toml
# Edit ota_devices.toml with your device IPs
poetry run python -m tools.deploy.ota_deploy  # Build and deploy to all devices

See Build & Deployment Guide for OTA updates, testing, and linting.

Host CLI

poetry install                             # Install dependencies

# Interactive TUI (serial)
poetry run python -m mirror_cli interactive --port /dev/ttyUSB0

# Interactive TUI (MQTT - control multiple nodes)
poetry run python -m mirror_cli interactive --transport mqtt

# Single commands
poetry run python -m mirror_cli move --port /dev/ttyUSB0 0 800
poetry run python -m mirror_cli home --port /dev/ttyUSB0 0 --overshoot 800

CLI source: tools/mirror_cli

MQTT Telemetry

Status Topic (devices/<mac>/status)

Real-time motor telemetry published at 1-5 Hz:

• Publishes aggregate snapshots (QoS0, non-retained)
• Payload: {"node_state":"ready","ip":"<ipv4>","motors":{"0":{...}}}
• Offline LWT: {"node_state":"offline","motors":{}}
• Cadence: 1 Hz idle, 5 Hz while motors moving, change-driven bursts between ticks
• Includes per-motor: position, moving state, thermal budget, speed, timing

Config Topic (devices/<mac>/config)

Device configuration published on change with retain=true:

• Publishes only when config changes (not every status update)
• Retained so new subscribers get current config immediately
• Payload: {"thermal_limiting":"ON","max_budget_s":90,"microstep":"1/32","microstep_mult":32,"speed":4000,"accel":16000,"decel":16000}
• Auto-publishes after SET THERMAL_LIMITING, SET MICROSTEP, or speed/accel changes

Connection Management

• Auto-reconnects with exponential backoff on broker loss

Runtime MQTT Configuration

MQTT:GET_CONFIG                            # Show active broker config
MQTT:SET_CONFIG host=<fqdn> port=<port>    # Update specific fields
MQTT:SET_CONFIG RESET                      # Reset to compile-time defaults

Schema: docs/mqtt-status-schema.md, docs/mqtt-config-schema.md, docs/mqtt-command-schema.md

Wi-Fi Onboarding

Devices support primary (home) and secondary (hotspot) networks with automatic failover.

1. Power device with no credentials (hold BOOT 5s to clear existing)
2. Join SOFT_AP_SSID_PREFIX + MAC using password from include/secrets.h
3. Browse to http://192.168.4.1/ to configure networks

Status LED (GPIO2): Fast blink = SoftAP active, Slow blink = Connecting, Solid = Connected

See Build & Deployment Guide for serial commands, HTTP API, and OTA updates.

Protocol Reference

MOVE:<id|ALL>,<abs_steps>[,<speed>][,<accel>]
HOME:<id|ALL>[,<overshoot>][,<backoff>][,<speed>][,<accel>][,<full_range>]
STATUS
WAKE:<id|ALL>
SLEEP:<id|ALL>
GET [ALL]
GET LAST_OP_TIMING[:<id|ALL>]
GET THERMAL_LIMITING
GET MICROSTEP
SET THERMAL_LIMITING=OFF|ON
SET MICROSTEP=FULL|HALF|1/4|1/8|1/16|1/32

Responses: CTRL:ACK (MOVE/HOME include est_ms), CTRL:ERR E.., CTRL:WARN ...

Full spec: Serial command protocol v1

Key Files

Component	Location
Firmware console	src/console/SerialConsole.cpp
Command processor	lib/MotorControl/src/MotorCommandProcessor.cpp
Command pipeline	lib/MotorControl/src/command/
Hardware controller	lib/MotorControl/src/HardwareMotorController.cpp
FastAccelStepper adapter	src/drivers/Esp32/FasAdapterEsp32.cpp
74HC595 driver	src/drivers/Esp32/Shift595Vspi.cpp
Constants	lib/MotorControl/include/MotorControl/MotorControlConstants.h
Board pins	include/boards/Esp32Dev.hpp
Wi-Fi onboarding	lib/net_onboarding/src/NetOnboarding.cpp
OTA manager	lib/ota_manager/src/OtaManager.cpp
Host CLI	tools/mirror_cli/
C++ tests	test/test_MotorControl/, test/test_Drivers/

Configuration

Build flags and motion constants are documented in the Build & Deployment Guide.
