Databricks Spark Application Starter Kit

Databricks Spark Application Starter Kit is a starter codebase for building and deploying Apache Spark applications on Databricks with production-ready structure and best practices.

Note

In short, this starter kit will help you to develop your Spark application locally and deploy it to Databricks Jobs with a single command, and schedule it to run periodically, using Databricks Connect, Databricks Unity Catalog, and Databricks Jobs (Python Wheel Task).

Table of Contents

• Databricks Spark Application Starter Kit
  • Table of Contents
  • Quick Start
  • Project Structure
  • Prerequisites for local development
  • Development Setup
  • Managing Table Writes with insert_overwrite and ManagedDataFrame
    • 1. Direct API with insert_overwrite
    • 2. Class-based API with ManagedDataFrame
    • Quick Comparison
  • Support backfilling data with job parameters
  • Example jobs already included
  • References

Quick Start

Run a sample job locally: (make sure you have followed the Development Setup steps and setup .env file)

spark_app --job_name sample_simple_job

Deploy the sample job to Databricks Jobs:

databricks_deploy --job_name sample_simple_job

Note

You can find the sample job code in src/databricks_spark_app/jobs/sample_simple_job.py. This only deploys the job to Databricks Jobs. You still need to schedule it in the Databricks UI under Schedules & Triggers.

Project Structure

databricks-spark-app-starter/
├── src/databricks_spark_app/
│   ├── jobs/               # the only folder you mostly work on and care about the most
│   │   ├── sample_simple_job.py   # example spark job, the file name will be used as job name
│   │   └── ...
│   ├── io
│   │   ├── dataframe.py    # ManagedDataFrame class for schema and comments management
│   │   └── writer.py       # insert_overwrite function for writing data to tables
│   ├── pipeline.py         # entry point for running spark jobs
│   ├── deploy.py           # script to deploy jobs to Databricks
│   ├── utils.py            # utility functions
│   └── config.py           # configuration management
└── ...                     # other project files

Prerequisites for local development

• Python 3.12+
• Databricks account with access to a workspace
  • You can sign up for a free edition: https://www.databricks.com/learn/free-edition
  • Generate a personal access token (PAT): https://docs.databricks.com/aws/en/dev-tools/auth#generate-a-token
• uv for python package management: https://docs.astral.sh/uv/installation

Development Setup

tl;dr: Clone the repo, install dependencies, set up environment variables, and start coding in src/databricks_spark_app/jobs/.

Important

If you are planning to change the folder name databricks_spark_app in the src directory, please make sure everywhere in the codebase is updated accordingly by searching for databricks_spark_app. (e.g ctrl + shift + f in VSCode)

1. Install dependencies:

   uv sync --all-groups --all-extras

   After that, a virtual environment will be created in the .venv directory.

2. Prepare environment variables:

   • Copy .env.example to .env and fill in your Databricks host and token.

     cp .env.example .env

   • Fill in your Databricks host and token in the .env file.

     DATABRICKS_HOST=your-databricks-host
     DATABRICKS_TOKEN=your-databricks-token

   • Source the .env file if needed:

     source .env

3. Develop your Spark application in the src/databricks_spark_app/jobs/*.py files with pipeline function as the entry point. Example:

   # src/databricks_spark_app/jobs/sample_simple_job.py
   import logging

   from pyspark.sql import SparkSession, Window
   from pyspark.sql import functions as f

   logger = logging.getLogger(__name__)


   def pipeline():
      # ... your Spark job logic here ...

4. Test your Spark application locally by adding job name as a command-line argument. Example:

   spark_app --job_name sample_simple_job

   2025-09-15 20:35:28,415 - databricks_spark_app.utils - INFO - Logging is set up.
   2025-09-15 20:35:32,612 - databricks_spark_app.utils - INFO - Initialized Spark 4.0.0 session.
   2025-09-15 20:35:32,612 - databricks_spark_app.utils - INFO - Running job: sample_simple_job
   +------------------+
   |           message|
   +------------------+
   |Hello, Databricks!|
   +------------------+

   2025-09-15 20:35:33,505 - databricks_spark_app.jobs.sample_simple_job - INFO - Sample job completed successfully.

   Note: The job name should match the filename in src/databricks_spark_app/jobs/.

5. Deploy your Spark application to Databricks:

   databricks_deploy --job_name sample_simple_job

   This will package your application and deploy it to Databricks Jobs. You can verify the deployment in the Databricks UI under Jobs & Pipelines.



   Job will be deployed as Python Wheel Task and will run on the latest Databricks Runtime with Spark 4.0+, which supports Python 3.12+ and treats the job like a DAG in Airflow.



6. Schedule your job under Schedules & Triggers in the Databricks Jobs UI.

   You can also trigger the job manually from the UI or scheduled it via cron expression.

Managing Table Writes with insert_overwrite and ManagedDataFrame

This starter kit provides two ways to manage writing data into Unity Catalog or Hive Metastore tables:

1. Direct functional API with insert_overwrite
2. Class-based abstraction with ManagedDataFrame

Choose whichever fits your workflow best.

1. Direct API with insert_overwrite

When to use: if your jobs are simple and you just need to persist results.

If you already have a Spark DataFrame and want to write it to a managed table with schema enforcement and comments:

import logging
from pyspark.sql import SparkSession
from pyspark.sql import types as t
from databricks_spark_app.io.writer import insert_overwrite

logger = logging.getLogger(__name__)

def pipeline():
   spark = SparkSession.getActiveSession()

   df = spark.sql("""
   SELECT
         'Hello, Databricks!' AS message,
         CAST(CURRENT_DATE() AS STRING) AS part_date
   """)

   df.show(truncate=False)
   force_schema = t.StructType([
      t.StructField("message", t.StringType(), nullable=False),
      t.StructField("part_date", t.StringType(), nullable=False),
   ])
   spark.sql("CREATE DATABASE IF NOT EXISTS temp_db")
   insert_overwrite(
      fqtn="temp_db.hello_table",
      spark_df=df,
      force_schema=force_schema,
      table_comment="Sample table for insert overwrite demonstration",
      column_comments={
            "message": "A greeting message",
            "part_date": "Partition date",
      },
      partition_by=["part_date"],
   )

   logger.info("Sample job completed successfully.")

2. Class-based API with ManagedDataFrame

When to use: if your jobs are complex and you want to encapsulate logic, schema, and comments in one place.

• You want strict schema management (table_schema required).
• You want column-level documentation via column_comments.
• You want to follow a standardized job template.

You can extend ManagedDataFrame to define schema, comments, and transformation logic in one place.

This makes jobs self-describing, reusable, and testable.

import logging
from pyspark.sql import SparkSession
from pyspark.sql import types as t
from databricks_spark_app.io.dataframe import ManagedDataFrame

logger = logging.getLogger(__name__)

class SampleHelloTable(ManagedDataFrame):
    table_comment = "Sample table for insert overwrite demonstration"
    column_comments = {
        "message": "A greeting message",
        "part_date": "Partition date",
    }
    table_schema = t.StructType([
        t.StructField("message", t.StringType(), nullable=False),
        t.StructField("part_date", t.StringType(), nullable=False),
    ])

    def process(self):
        spark = SparkSession.getActiveSession()
        return spark.sql("""
            SELECT
                'Hello, Databricks! From ManagedDataFrame' AS message,
                CAST(CURRENT_DATE() AS STRING) AS part_date
        """)

def pipeline():
    job = SampleHelloTable()
    job.insert_overwrite(fqtn="temp_db.hello_table", partition_by=["part_date"])
    logger.info("Sample job completed successfully.")

Quick Comparison

Feature	insert_overwrite (function)	ManagedDataFrame (class)
Minimal boilerplate	Yes	No, requires class define
Schema enforcement	Manual	Automatic (table_schema)
Column-level documentation	Manual	Automatic (column_comments)
Best for	Simple jobs	Complex/production jobs

Support backfilling data with job parameters

You can define additional job parameters in DatabricksAdditionalParams in config.py. These parameters will be automatically added as command-line arguments when running the job locally or in Databricks Jobs. You can then access these parameters in your job code via Spark SQL variables with the syntax `params.<param_name>`. Note that the sign is the backtick (`), not a single quote (').

Example:

spark.sql("""
   SELECT *
   FROM some_table
   WHERE part_date = `params.run_date`
""")

When running locally:

spark_app --job_name sample_run_date_job.py --run_date "2025-09-01"

Because the Spark Connect session doesn't support setting or changing Spark configurations, the only way to pass parameters is Spark variables (https://spark.apache.org/docs/4.0.0/sql-ref-syntax-ddl-declare-variable.html).

Example jobs already included

In the src/databricks_spark_app/jobs folder, you will find several example jobs demonstrating different features:

├── jobs
│   ├── sample_insert_overwrite.py
│   ├── sample_managed_table.py
│   ├── sample_run_date_job.py
│   └── sample_simple_job.py

Just replace/delete these example jobs with your own job files as needed.

References

• Databricks Jobs: https://docs.databricks.com/aws/en/jobs
• Databricks Connect For Python: https://docs.databricks.com/aws/en/dev-tools/databricks-connect/python/
• PySpark Documentation: https://spark.apache.org/docs/4.0.0/api/python/index.html
