Iciclecreek.Avalonia.Terminal

A cross-platform XTerm terminal emulator control for Avalonia UI applications.

Introduction

Iciclecreek.Avalonia.Terminal provides Avalonia controls for embedding a fully-featured terminal emulator in your cross-platform desktop applications. Built on top of XTerm.NET for terminal emulation and Porta.Pty for pseudo-terminal support, it offers:

• Full XTerm-compatible terminal emulation
• Cross-platform support (Windows, Linux, macOS)
• Scrollback buffer with configurable size
• Text selection and clipboard support
• Terminal window manipulation commands (resize, move, minimize, maximize, etc.)
• Dynamic title updates from terminal escape sequences
• Customizable fonts, colors, and styling

Installation

Install via NuGet Package Manager:

dotnet add package Iciclecreek.Avalonia.Terminal

Or via the Package Manager Console in Visual Studio:

Install-Package Iciclecreek.Avalonia.Terminal

Usage

TerminalControl

TerminalControl is a templated control that provides a terminal view with an integrated scrollbar. Use this when you want to embed a terminal within your own window or layout.

XAML:

<Window xmlns="https://github.com/avaloniaui"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:terminal="using:Iciclecreek.Terminal"
        x:Class="MyApp.MainWindow">

    <terminal:TerminalControl x:Name="Terminal"
                              FontFamily="Cascadia Mono"
                              FontSize="14"
                              BufferSize="1000"
                              ProcessExited="OnProcessExited"/>
</Window>

Code-behind:

using Avalonia.Controls;
using Iciclecreek.Terminal;

public partial class MainWindow : Window
{
    public MainWindow()
    {
        InitializeComponent();
    }

    private void OnProcessExited(object? sender, ProcessExitedEventArgs e)
    {
        // Handle process exit (e.g., close window)
        Close();
    }
}

Properties:

Property	Type	Default	Description
Process	string	cmd.exe (Windows) / sh (Unix)	The shell or process to launch
Args	IList<string>	Empty	Command-line arguments for the process
StartingDirectory	string?	Current working directory	The initial working directory used when launching the PTY process
CurrentDirectory	string?	Read-only	The current working directory reported by the running terminal session via OSC 7
ExitCode	int	Read-only	The exit code of the launched process after it has terminated
Pid	int	Read-only	The operating system process identifier of the launched terminal process
BufferSize	int	1000	Scrollback buffer size (number of lines)
FontFamily	FontFamily	Inherited	Terminal font family (use monospace fonts)
FontSize	double	Inherited	Terminal font size
Foreground	IBrush	Inherited	Default text color
Background	IBrush	Inherited	Terminal background color
SelectionBrush	IBrush	Semi-transparent blue	Text selection highlight color

Methods:

Method	Description
LaunchProcess()	Launches the configured Process with the current Args and StartingDirectory
LaunchProcess(string? startingDirectory, string process, params string[] args)	Convenience overload that sets StartingDirectory, Process, and Args, then launches the process
Kill()	Terminates the running terminal process
WaitForExit(int ms)	Waits for the terminal process to exit or for the specified timeout to elapse

Events:

Event	Description
ProcessExited	Raised when the PTY process exits. The handler receives ProcessExitedEventArgs with the process ExitCode.

TerminalWindow

TerminalWindow is a complete window implementation that automatically handles terminal events like title changes and window manipulation commands. Use this when you want a standalone terminal window.

XAML:

<terminal:TerminalWindow xmlns="https://github.com/avaloniaui"
                         xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
                         xmlns:terminal="using:Iciclecreek.Terminal"
                         x:Class="MyApp.TerminalWindow"
                         Title="Terminal"
                         Width="800"
                         Height="600"
                         FontFamily="Consolas"
                         FontSize="12"
                         Background="Black"
                         Foreground="White"
                         CloseOnProcessExit="True"
                         UpdateTitleFromTerminal="True"
                         HandleWindowCommands="True"/>

Or create programmatically:

using Iciclecreek.Terminal;

var terminalWindow = new TerminalWindow
{
    Title = "My Terminal",
    Width = 800,
    Height = 600,
    FontFamily = new FontFamily("Cascadia Mono"),
    FontSize = 14,
    StartingDirectory = Environment.CurrentDirectory,
    Process = "pwsh.exe",  // PowerShell Core
    Args = new[] { "-NoLogo" },
    CloseOnProcessExit = true
};

terminalWindow.Show();

Methods:

Method	Description
LaunchProcess()	Launches the configured Process with the current Args and StartingDirectory
LaunchProcess(string? startingDirectory, string process, params string[] args)	Convenience overload that sets StartingDirectory, Process, and Args, then launches the process
Kill()	Terminates the running terminal process
WaitForExit(int ms)	Waits for the terminal process to exit or for the specified timeout to elapse

Additional Properties (beyond TerminalControl):

Property	Type	Default	Description
ExitCode	int	Read-only	The exit code of the launched process after it has terminated
Pid	int	Read-only	The operating system process identifier of the launched terminal process
CloseOnProcessExit	bool	true	Automatically close the window when the process exits
UpdateTitleFromTerminal	bool	true	Update window title from terminal escape sequences
HandleWindowCommands	bool	true	Handle window manipulation commands from the terminal

Events:

Event	Description
ProcessExited	Raised when the PTY process exits. The handler receives ProcessExitedEventArgs with the process ExitCode. If CloseOnProcessExit is true, the event is raised before the window closes.

Links

• GitHub Repository: https://github.com/tomlm/Iciclecreek.Avalonia.TerminalWindow
• NuGet Package: https://www.nuget.org/packages/Iciclecreek.Avalonia.Terminal
• XTerm.NET: https://github.com/tomlm/XTerm.NET
• Porta.Pty: https://github.com/tomlm/Porta.Pty
• Avalonia UI: https://avaloniaui.net/

License

This project is licensed under the MIT License - see the LICENSE file for details.
